Optokon LMSW-83M Ruggedized Gigabit Ethernet Layer 2 Managed PoE Switch
3x 100/1000Base-X FO HMA 8x 10/100/1000Base-T, RJ-45 with PoE+ The LMSW-83M is a military-grade Layer 2 managed switch featuring 3x fiber HMA-J ports (Gigabit or Fast Ethernet) and 8x 10/100/1000Base-T RJ-45 ports with PoE+ functionality, providing stable and reliable Ethernet transmission. The LMSW-M series models offer excellent performance for optical data networks and a rugged design. The switch supports a variety of management functions, including STP/RSTP/MSTP and ITU-T G.8032 Ring <50 ms recovery time, advanced PoE management features such as automatic PoE device checking and automatic reset, Layer 2 Ethernet IGMP, VLAN, QoS, security, IPv6, bandwidth control, port mirroring, cable diagnostics, and Green Ethernet. The switch can simultaneously connect to all common 12/24 V DC and 230 V AC power supply systems (redundant power supply). The switch operates in a wide temperature range from -40 to +70 °C. It can be used as a standalone device or installed in a 19-inch rack using 19-inch mounting brackets.
Properties
- Rugged, compact design that withstands harsh environmental conditions and rough handling
- Front: 8x 10/100/1000Base-T:
- RJ-45 interface with IEEE802.3af/at PoE output support (30 W per port, up to 180 W)
- Rear: 3x 100/1000Base-X FO ports with HMA-J connectors
- Integrated power booster design up to 55 V DC for PoE/PoE+ output
- Redundant AC/DC power supply with dual inputs available
